LSU Patrick School of Engineering

PATRICK TAYLOR COLLEGE OF ENGINEERING – LSU
Gaudin Equipment & Supply Company, Inc.

Technical Specifications:

  • Heat Transfer System: Model HTS-8000 – 1965 GPM @ 80’ TDH, 160º to 180º
  • Dimensions: Approximately 18 ft. long x 9 ⅓ ft. wide x 13 ¼ feet high
  • Steam Control Assembly (⅓-⅔ valves) with by-pass and drip trap
  • 60 HP Taco Pumps (duplex)
  • Special TIGER’S EYE MARK VI HVAC Controls
  • 60 HP Variable Frequency Drives
  • 12” Suction & Discharge Headers
  • Flow Sensor
  • Endraus Hauser Differential Pressure Transmitter
  • Condensate traps and return system
  • Single heat exchanger
